25 kVA Air Cooled Servo Voltage Stabilizer

Name: 25 kVA Air Cooled Servo Voltage Stabilizer
Brand: HINDUSTAN POWER PRODUCTS (P) LTD.
Price: 74500 INR
Availability: InStock

74500 INR/Piece

Get a Price/Quote

Product Details:

Power Rating 25 kVA, 3 Phase, 4 Wire
Input Voltage 280V to 460V Volt (V)
Output Voltage 400V +/- 1% Volt (V)
Frequency (MHz) 47-63 Hertz (HZ)
Efficiency 98-99%
Phase Three Phase
Warranty 1 Year
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

25 kVA Air Cooled Servo Voltage Stabilizer Price And Quantity

Minimum Order Quantity 1 Piece
Price 74500 INR/Piece

25 kVA Air Cooled Servo Voltage Stabilizer Product Specifications

Weight 148 Kilograms (kg)
Ambient Temperature -20 to 50 Celsius (oC)
Waveform Distortion Nil
Input Voltage 280V to 460V Volt (V)
Phase Three Phase
Warranty 1 Year
Frequency (MHz) 47-63 Hertz (HZ)
Power Rating 25 kVA, 3 Phase, 4 Wire
Dimension (L*W*H) L 550 x D 500 x H 1000 Millimeter (mm)
Output Voltage 400V +/- 1% Volt (V)
IP Rating IP30
Efficiency 98-99%

25 kVA Air Cooled Servo Voltage Stabilizer Trade Information

FOB Port Delhi
Supply Ability Per Day
Delivery Time 15 Days
Packaging Details Wooden Pallet / Wooden Box
Main Export Market(s) Middle East, Africa, Asia
Main Domestic Market All India
Certifications IS 9815, ISO 9001-2015, ISO 14001-2015 CE Conformity EN61558-1:2005+A1:2009

Product Description

Technical Specifications - Model SVS28A325

Rating	:	25 kVA, 3 Phase, 4 Wire
Output Current	:	36 Amps per phase
Input Voltage Range	:	340V to 460V, 47Hz to 63Hz, 4 Wire
Output Voltage	:	400V +/- 1%
Duty Cycle	:	Continuous 24x7
Input / Output Termination	:	On Brass studs / Connectors
Response Time	:	Less than 10ms
Suitability	:	Suitable for all power factor loads
Cooling	:	Natural air Cooled
Installation	:	Indoor type
Degree of Protection	:	IP-30
No Load Loss	:	Less than 0.4%
Efficiency	:	98-99%
Winding & Wiring Material	:	Copper EC grade (99.9% Pure)
Technology	:	Torridly wound Variable Auto Transformer for linear control and greater efficiency.
Drive	:	Direct AC drive for fastest voltage correction and durability
Wave form Distortion	:	Nil
Correction Speed	:	Faster than 24V per sec.
Controls	:	All the three phases controlled individually for better voltage and load management.
Size (in mm) & Weight	:	L 550 x D 500 x H 1000 & 148 Kg.
Applicable Standard	:	IS 9815
	:	ISO 9001-2015 , ISO 14001-2015
International Marking	:	CE Conformity EN61558-1:2005+A1:2009

Optional Protections

Overload Cut-Off and Short Circuit Protection.
Low/High Voltage (out of input range) Alarm or Cut-Off.
Phase Missing / Phase Reversal Alarm or Cut-Off.

Optional Features

Digital Multifunction Meter. Manual Bypass & Auto Phase Correction

Salient Features

"IC" based solid-state, relay less, plug in control cards for easy online serviceability.
Output voltage adjustable 6% of set voltage from front panel.
Meters on front panel for easy monitoring of input and output voltage along with limit indicators.
Provision for Auto / Manual control from the front panel.
Wide ambient temperature operation from -20C to 50C.
Due to new innovations & improvements the technical specifications are subject to change.

Advanced Automatic Voltage Control

Powered by an intelligent automatic control system, this servo voltage stabilizer meticulously adjusts voltage output to maintain consistency, even under fluctuating input conditions. This proactive correction protects your devices and enhances their lifespan, ensuring smooth operations for any connected machinery or appliance.

Energy Efficiency and Reliability

With a remarkable efficiency rating of 98%, this stabilizer minimizes energy loss and offers cost-effective performance, making it suitable for continuous operation. Its air-cooled mechanism ensures reliable heat dissipation, adding to long-term stability and operational safety, especially in demanding environments.
