30 kVA Air Cooled Servo Voltage Stabilizer

Product Description

Technical Specifications - Model SVS32A330

Rating	:	30 kVA, 3 Phase, 4 Wire
Output Current	:	43 Amps per phase
Input Voltage Range	:	320V to 460V, 47Hz to 63Hz, 4 Wire
Output Voltage	:	400V +/- 1%
Duty Cycle	:	Continuous 24x7
Wave form Distortion	:	Nil
Response Time	:	Less than 10ms
Suitability	:	Suitable for all power factor loads
Cooling	:	Natural air Cooled
Installation	:	Indoor type
Degree of Protection	:	IP-30
No Load Loss	:	Less than 0.4%
Efficiency	:	98-99%
Correction Speed	:	Faster than 28V per sec.
Input / Output Termination	:	On Brass studs / Connectors
Winding & Wiring Material	:	Copper EC grade (99.9% Pure)
Technology	:	Torridly wound Variable Auto Transformer for linear control and greater efficiency.
Drive	:	Direct AC drive for fastest voltage correction and durability
Controls	:	All the three phases controlled individually for better voltage and load management.
Size (in mm) & Weight	:	L 550 x D 500 x H 1000 & 167 Kg.
Applicable Standard	:	IS 9815
	:	ISO 9001-2015 , ISO 14001-2015
International Marking	:	CE Conformity EN61558-1:2005+A1:2009

Optional Protections

• Overload Cut-Off and Short Circuit Protection.
• Low/High Voltage (out of input range) Alarm or Cut-Off.
• Phase Missing / Phase Reversal Alarm or Cut-Off.

Optional Features

• Digital Multifunction Meter. Manual Bypass & Auto Phase Correction

Salient Features

• "IC" based solid-state, relay less, plug in control cards for easy online serviceability.
• Output voltage adjustable  6% of set voltage from front panel.
• Meters on front panel for easy monitoring of input and output voltage along with limit indicators.
• Provision for Auto / Manual control from the front panel.
• Wide ambient temperature operation from -20C to 50C.
• Due to new innovations & improvements the technical specifications are subject to change.

Superior Voltage Regulation for Industry

Designed to maintain consistent voltage levels, the 30 kVA Air Cooled Servo Voltage Stabilizer protects machinery and electrical devices from voltage fluctuations. Its automatic control system and high-efficiency rating make it a dependable solution for industrial and commercial applications, ensuring continuous workflow and reduced equipment downtime.


Exporter and Manufacturer in India

As a trusted manufacturer and exporter from India, we ensure quality and reliability in each stabilizer unit. Our focus on using robust components and efficient air-cooled technology guarantees lasting performance, making our stabilizers a preferred choice across domestic and international markets.
